Publication 1734-UM001D-EN-P - April 2008
POINT I/O Module Data 99
Digital ac Input Modules
The 1734 digital ac input modules feature the following:
• 120 or 220V ac nominal are ac inputs
• Input range of 65…132 for 120V ac inputs; 159…264 for 220V ac
inputs
• Two sinking style inputs
• Autobaud (will match baud of existing devices on the network)
• Selectable input filter times (0…65 ms with 1 ms default)
• Sequential auto addressing
Default Data Map for 1734-IB4D Module - - Configuration Assembly Instance 103
Message Size: 18 Bytes
7 6543 2 1 0
Consume 0 Input 0 Off to On Filter Byte 0
Consume 1 Input 0 Off to On Filter Byte 1
Consume 2 Input 0 On to Off Filter Byte 0
Consume 3 Input 0 On to Off Filter Byte 1
Consume 4 Input 1 Off to On Filter Byte 0
Consume 5 Input 1 Off to On Filter Byte 1
Consume 6 Input 1 On to Off Filter Byte 0
Consume 7 Input 1 On to Off Filter Byte 1
Consume 8 Input 2 Off to On Filter Byte 0
Consume 9 Input 2 Off to On Filter Byte 1
Consume 10 Input 2 On to Off Filter Byte 0
Consume 11 Input 2 On to Off Filter Byte 1
Consume 12 Input 3 Off to On Filter Byte 0
Consume 13 Input 3 Off to On Filter Byte 1
Consume 14 Input 3 On to Off Filter Byte 0
Consume 15 Input 3 On to Off Filter Byte 1
Consume 16 Autobaud Disable Enable OW3 Enable OW2 Enable OW1 Enable OW0
Consume 17 Produced Assembly Instance
Produce (Tx) No produced data
Where: OW = open wire.
