Install POINT I/O Modules 49
1734-OX2 2-relay Output Modules
ATTENTION
Relay contacts are not powered by the internal
power bus. Load power can be provided by the
internal power bus or an external power source.
41974
Module Status
Network Status
Status of Output 0
Status of Output 1
Output 0 Relay Common - RC
+V
RC - Output 1 Relay Common
+V
Output 0 Connection - NC
Output 0 Connection - NO
NC - Output 1 Connection
NO - Output 1 Connection
NC = Normally closed
NO = Normally open
RC = Relay Common
+V = Positive Supply
