Publication 1734-UM001D-EN-P - April 2008
186 Configure POINT I/O Modules in RSLogix 5000 Software
About Fault/Program Action and Configuration Dialogs
You see Fault/Program Action and Configuration dialogs based on the
module and connection types. Refer to the following table.
Understanding Data and Connection Formats
For digital modules, the choices for data format and connection type are as
follows:
• Data Format - Integer
• Connection Type - Data, Listen only, Listen only - rack optimization,
Rack optimization
When you change entries for data format and connection type, note:
• You do not delete the existing module.
• You do not create a new module.
• You bring forward configuration data for the new settings.
• Any configuration data you do not bring forward sets to the default
value.
After you apply new settings for data format and connection, note the
following:
• This is the base configuration for the next change in connection and
data format settings.
• You lose all configuration data from previous data formats.
For Module Type With Connection Type
You See These Tabs
(1)
Fault/Program Action Configuration
Input Data x
Listen Only
Listen Only - Rack Optimization
Rack Optimization x
Output Data x x
Listen Only
Listen Only - Rack Optimization
Rack Optimization x x
(1)
You see tabs for General, Connection, and Module Info for all module and connection types.
