Rockwell Automation POINTBlock Series User Manual

Publication 1734-UM001D-EN-P - April 2008
94 Install POINTBlock I/O Modules
DeviceNet Connector Wiring
1734D-IB16 POINTBlock 16 dc Input Modules
DeviceNet
Connection
Red
White
Bare
Blue
Black
-V
42132
+V
CAN - High
Shield
CAN - Low
42004
10’s Node Address Rotary Switch
1’s Node Address Rotary Switch
Module Status
Network Status
I/O status
