Rockwell Automation POINTBlock Series User Manual

Publication 1734-UM001D-EN-P - April 2008
Default Data Maps 169
1734-IA2 Input Module
Message Size: 1 Byte
1734-IA4 Input Module
Message Size: 1 Byte
1734-IM2 Input Module
Message Size: 1 Byte
1734-IM4 Input Module
Message Size: 1 Byte
76543210
Produces (scanner Rx) Ch1 Ch0
Consumes (scanner Tx) No consumed data
Where:Ch0 = channel 0, Ch1 = channel 1; 0 = off, 1 = on
76543 2 1 0
Produces (scanner Rx) Ch3 Ch2 Ch1 Ch0
Consumes (scanner Tx) No consumed data
Where:Ch0 = channel 0, Ch1 = channel 1, Ch2 - channel 2, Ch3 = channel 3 0 = Off, 1 = On
76543210
Produces (scanner Rx) Ch1 Ch0
Consumes (scanner Tx) No consumed data
Where: Ch 0 = channel 0, Ch 1 = channel 1; 0 = off, 1 = on
76543 2 1 0
Produces (Rx) Ch3 Ch2 Ch1 Ch0
Consumes (Tx) No consumed data
Where:Ch0 = channel 0, Ch1 = channel 1, Ch2 - channel 2, Ch3 = channel 3 0 = Off, 1 = On
