Preface
Purpose of This Manual
This manual describes how to install, configure, and troubleshoot your
POINT I/O modules.
The POINT I/O modules in this manual are DeviceNet ready. Each module
can exist on the DeviceNet network as one of the following:
• As an individual node
• With an adapter (catalog number 1734-ADN or 1734-ADNX) as a
single node
When using these POINT I/O modules with an adapter, use this manual in
conjunction with the user manual for the adapter you are using as shown in the
table.
For applications using these modules in a network with a 1734-PDN
DeviceNet Communication Interface, or a 1734D-xx POINTBlock I/O
module, this user manual is the primary documentation.
Who Should Use This
Manual
In this manual, we assume you know how to do the following:
• Use RSNetWorx software or similar configuration software to set up
and calibrate these modules.
• Have the capability to download and use electronic data sheet (EDS)
files.
If you do not, refer to your software documentation or online help before
attempting to use these modules.
When Using POINT I/O
Modules on This
Network
Refer to User Manual
for
Cat. No. Publication No.
DeviceNet network DeviceNet adapter 1734-ADN
1734-ADNX
1734-UM002
ControlNet network ControlNet adapter 1734-ACNR 1734-UM008
EtherNet/IP network EtherNet/IP adapter 1734-AENT 1734-UM011
PROFIBUS network PROFIBUS adapter 1734-APB 1734-UM005
