Rockwell Automation POINTBlock Series User Manual

Publication 1734-UM001D-EN-P - April 2008
150 Troubleshoot with the Indicators
1734-OA2 and 1734-OA4 120/220V ac Output Module
1734-IM2 and 1734-IM4 220V ac Input Module
Module Status
Network Status
Status of Output 0
Status of Output 1
44209
Module Status
Network Status
Status of Output 0
Status of Output 1
Status of Output 2
Status of Output 3
44210
1734-OA2
1734-OA4
Indication Probable Cause Recommended Action
I/O Status
Off All outputs are inactive. None.
Yellow One or more outputs is active and under control. None.
Module Status
Network Status
Status of Input 0
Status of Input 1
44211
Module Status
Network Status
Status of Input 0
Status of Input 1
Status of Input 2
Status of Input 3
1734-IM2
1734-IM4
Indication Probable Cause
Recommended Action
I/O Status
Off Input is in the off-state None.
Yellow Input is in the on-state None.
