Rockwell Automation POINTBlock Series User Manual

Publication 1734-UM001D-EN-P - April 2008
Install POINT I/O Modules 63
Wiring Power Distribution
and Other Modules
1734-PDN Communication Interface Module
1734-PDN Module Wiring Diagram
41970
System Power
CHAS GND
C
V
NC
CHAS GND
C
V
NC
DeviceNet Connector
DeviceNet Power
NC = No Connection
CHAS GND = Chassis Ground
C = Common
V = Supply
V dc
NC
CHAS
GND
C
V
NC
C
V
This supply will be
connected to the internal
field power bus.
12/24V dc
Power
NC = No Connection
CHAS GND = Chassis Ground
C = CommonV = Supply
CHAS
GND
3
5
7
0
1
2
4
6
