Publication 1734-UM001D-EN-P - April 2008
POINT I/O Module Data 117
Channel Indicators
See the table for channel indicator states for given module condition.
POINTBlock I/O Modules
Mount these 1734D input/output modules on DIN rail with an integrated
DeviceNet communication interface, 8 inputs and 8 outputs, removable
terminations, and a POINTBus expansion port.
The modules include a non-isolated DeviceNet communication interface. The
24V dc from the DeviceNet connection powers a non-isolated dc/dc
converter that generates +5V dc that powers the POINTBlock electronics and
connects to the POINTBus port to power the expansion I/O electronics.
Indication 1734-OE2C Probable Cause 1734-OE2V Probable Cause
Channel Status
Off Module in CAL mode Module in CAL mode
Solid green Channel actively controlling outputs Channel actively controlling outputs
Blinking green Channel calibrating Channel calibrating
Blinking red Open wire or no power Low/High Clamp alarm
Solid red Unrecoverable fault - may require
device replacement
Loss of field power
Module Termination Voltage
Cage-clamp Spring-clamp
1734D-IB8XOB8E X 12/24V dc
1734D-IB8XOB8ES X
1734D-IB8XOW8 X 12/24V dc
1734D-IB8XOW8S X
1734D-IA8XOA8 X 120V ac
1734D-IA8XOA8S X
1734D-IA8XOW8 X 120V ac
1734D-IA8XOW8S X
1734D-IA16 X 120V ac
1734D-IA16S X
1734D-IB16 X 12/24V dc
1734D-IB16S X
