68 Install POINT I/O Modules
1734-EP24DC Expansion Power Supply
12/24v dc Wiring Diagram
ATTENTION
Use the 1734-EP24DC expansion power supply only with
adapter class products. This 1734-EP24DC power supply cannot
be used with a 1734-PDN module or 1734D POINTBlock
modules. Do not connect 120/240V ac power to this supply.
41970
C
V
NC
C
V
NC
NC = No Connection
CHAS GND = Chassis Ground
C = Common
V = Supply
CHAS GND
CHAS GND
System
Power
Field
Power
1734-EP24DC
NC NC
C
VV
C
V dc
V = 12/24V dc, C = Common
CHAS GND = Chassis ground
This dc supply is
connected to the
internal power bus.
3
5
7
01
2
4
6
Do not connect 120/240V ac
power to this supply.
EP24
CHAS
GND
CHAS
GND
