Rockwell Automation POINTBlock Series - 1734-OV8 E Output Module; 1734-OW2 Relay SinkSource Output Module; 1734-OW4 Relay SinkSource Output Module

Publication 1734-UM001D-EN-P - April 2008
Default Data Maps 173
1734-OV8E Output Module
Message Side: 1 Byte
Message Size: 1 Byte
1734-OW2 Relay Sink/Source Output Module
Message Size: 1 Byte
1734-OW4 Relay Sink/Source Output Module
Message Size: 1 Byte
76543210
Produces (scanner Rx) Ch7 Ch6 Ch5 Ch4 Ch3 Ch2 Ch1 Ch0 Channel status
Where: 0 = no error 1 = error
76543210
Consumes (scanner Tx) Ch7 Ch6 Ch5 Ch4 Ch3 Ch2 Ch1 Ch0 Channel state
Where: 0 = no error 1 = error
76543210
Consumes (scanner Tx) Not used Ch1 Ch0 Channel
state
Where: 0 = off 1 = on
76543210
Consumes (scanner Tx) Not used Ch3 Ch2 Ch1 Ch0 Channel state
Where: 0 = off 1 = on
