Rockwell Automation POINTBlock Series User Manual

Publication 1734-UM001D-EN-P - April 2008
Install POINT I/O Modules 65
1734-FPD Field Potential Distributor Module
1734-FPD Modules for 12/24V dc Wiring Diagram
Connect Terminal
+V dc 6
-V dc 4
Chas Gnd 2
12/24V dc becomes the internal power bus for modules to the right.
41970
C
V
NC
C
V
NC
NC = No Connection
CHAS GND = Chassis Ground
C = Common V = Supply
CHAS GND
CHAS GND
NC NC
C
VV
C
V dc
V = 12/24V dc, C = Common
CHAS GND = Chassis ground
This supply will be
connected to the
internal power bus.
3
5
7
01
2
4
6
CHAS
GND
CHAS
GND
