Rockwell Automation POINTBlock Series - 1734-OB4 E, 1734-OB4 Electronically Protected Output Module; 1734-OB8 E, 1734-OB8 Electronically Protected Output Module; 1734-OB2 EP Protected Output Module

Publication 1734-UM001D-EN-P - April 2008
Default Data Maps 171
1734-OB4E, 1734-OB4 Electronically Protected Output Module
Message Size: 1 Byte
Message Size: 1 Byte
1734-OB8E, 1734-OB8 Electronically Protected Output Module
Message Size: 1 Byte
Message Size: 1 Byte
1734-OB2EP Protected Output Module
Message Size: 1 Byte
76543210
Produces (scanner Rx) Not used Ch3 Ch2 Ch1 Ch0 Channel status (1734-OB4E only)
Where: 0 = no error 1 = error
76543210
Consumes (scanner Tx) Not used Ch3 Ch2 Ch1 Ch0 Channel state
Where: 0 = off 1 = on
76543210
Produces (scanner Rx) Ch7 Ch6 Ch5 Ch4 Ch3 Ch2 Ch1 Ch0 Channel status (1734-OB8E only)
Where: 0 = no error 1 = error
76543210
Consumes (scanner Tx) Ch7 Ch6 Ch5 Ch4 Ch3 Ch2 Ch1 Ch0 Channel state
Where: 0 = off 1 = on
76543 2 1 0
Produces (scanner Rx) Not used Ch1 Ch0 Channel status
Where:0 = no error, 1 = error
