Publication 1734-UM001D-EN-P - April 2008
102 POINT I/O Module Data
Digital ac Output Modules
The 1734-OA2 ac output module features include the following:
• 120V ac outputs with a range of 74…264V ac (120/220V ac nominal)
• Each output is rated at 0.10 A minimum to 0.75 A maximum
• Autobaud (will match baud of existing devices on the network)
• Sequential auto addressing
Default Data Map for the 1734-OB2EP Output Module
Message Size: 1 Byte
76543 2 1 0
Produces
(scanner Rx)
Not used Ch1 Ch0 Channel status
Where: 0 = no error, 1 = error
Message Size: 1 Byte
76543 2 1 0
Consumes
(scanner Tx)
Not used Ch1 Ch0 Channel state
Where: 0 = Off, 1 = On
D
efault Data Map for the 1734-OA2 Output Module
76543 2 1 0
Produces (scanner Rx) No produced data
Consumes (scanner Tx) Not used Ch1 Ch0 Channel state
Where: 0 = Off, 1 = On
Default Data Map for 1734-OA4 Modules
76543 2 1 0
Produces (scanner Rx) No produced data
Consumes (scanner Tx) Not used Ch 3 Ch 2 Ch1 Ch0 Channel state
Where: 0 = Off, 1 = On
