Publication 1734-UM001D-EN-P - April 2008
74 Install POINT I/O Modules
1734-ARM Address Reserve Module
1734-CTM and 1734-VTM Modules
The 1734-ARM
module requires no
external wiring.
41974
NC
NC
NC
NC
NC
NC
NC
NC
NC = No connection
1734
VTM
0
1
1734
CTM
0
1
1734-VTM
1734-CTM
Voltage Out
Voltage Out
Voltage Out
Voltage Out
Common
Common
Common
Common
43929
Voltage Out = 0 to 7
Common = 0 to 7
Common
Common
Common
Common
Voltage Out
Voltage Out
Voltage Out
Voltage Out
