Rockwell Automation POINTBlock Series - 1734-IV2 Source Input Module; 1734-IV4 Source Input Module; 1734-IV8 Source Input Module

Publication 1734-UM001D-EN-P - April 2008
168 Default Data Maps
1734-IV2 Source Input Module
Message Size: 1 Byte
1734-IV4 Source Input Module
Message Size: 1 Byte
1734-IV8 Source Input Module
Message Size: 1 Byte
Consume 17 Produced Assembly Instance
Produce (Tx) No produced data
Where: OW = open wire.
Default Data Map - Configuration Assembly Instance 103
Message Size: 18 Bytes
76543210
Produces (scanner Rx) Ch1 Ch0
Consumes (scanner Tx) No consumed data
Where: Ch 0 = input channel 0 data Ch 1 = input channel 1 data
76543210
Produces (scanner Rx) Ch3 Ch1 Ch1 Ch0
Consumes (scanner Tx) No consumed data
Where: Ch 0 = input channel 0 Ch 1 = input channel 1 Ch 2 = input channel 2 Ch 3 = input channel 3
76543210
Produces (scanner Rx) Ch7 Ch6 Ch5 Ch4 Ch3 Ch1 Ch1 Ch0
Consumes (scanner Tx) No consumed data
Where: Ch 0 = input channel 0 Ch 1 = input channel 1 Ch 2 = input channel 2 Ch 3 = input channel 3 Ch 4 = input channel 4 Ch 5 = input channel 5
Ch 6 = input channel 6 Ch 7 = input channel 7
