Publication 1734-UM001D-EN-P - April 2008
176 Default Data Maps
1734-OE2V Analog Voltage Output Module
Message Size: 4 bytes
Message Size: 2 Bytes
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Consumes (scanner Tx) Output Channel 0 High Byte Output Channel 0 Low Byte
Output Channel 1 High Byte Output Channel 1 Low Byte
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Produces (scanner Rx) Channel 1 Status - High Byte Channel 0 Status - Low Byte
Not used HCA LCA CM ST Not used HCA LCA CM ST
Where:ST = Channel Fault Status; 0 = no error, 1 = fault CM = Calibration Mode; 0 = normal, 1 = calibration mode
LCA = Low Clamp Alarm; 0 = no error, 1 = fault HCA = High Clamp Alarm; 0 = no error, 1 = fault
