80 Install POINTBlock I/O Modules
Output Wiring Diagram
Outputs are electronically protected to 0.75 A. Module outputs are selectable
for latched mode or auto-reset mode. (Latched/auto reset is set by module,
not by individual channel.) Each channel is assigned a bit in the data table to
indicate the faulted condition. Outputs in the latched mode can only be reset
with a user command to the module.
Output Terminal Common Terminal Power
Remote Termination Block 3
Channel 0 0 6
Channel 1 1 7
Channel 2 2 4
Channel 3 3 5
Remote Termination Block 4
Channel 4 0 6
Channel 5 1 7
Channel 6 2 4
Channel 7 3 5
Module power is supplied from the internal power bus.
ATTENTION
When connecting more then one wire in a termination point,
make sure that both wires are the same gauge and type.
Out 0
Out 1
Out 3Out 2
CC
CC
Load Load
42015
Load
Load
V = 12/24V dc, C = Common
Field power is supplied from internal power bus
0
2
6
3
1
7
45
To Next Page
