Rockwell Automation POINTBlock Series User Manual

Publication 1734-UM001D-EN-P - April 2008
Install POINTBlock I/O Modules 81
Latch Mode Functionality
To reset an output, the reset bit for the output can be set, or the output bit
must be cycled off/on.
Auto Retry Mode Functionality
In auto retry, the output recovers once the fault is removed.
DeviceNet Connector Wiring
State Indication Error Bit
Off Dark 0
On Yellow 0
Faulted/On Red 1
Faulted/Off Flashing Red 1
State Indication Error Bit
Off Dark 0
On Yellow 0
Faulted/On Red 1
Faulted/Off Flashing Red 1
DeviceNet
Connection
Red
White
Bare
Blue
Black
-V
42132
+V
CAN - High
Shield
CAN - Low
