17 Publication 1734-UM001D-EN-P - April 2008
Chapter
1
About the Modules
About This Chapter
This chapter introduces POINT I/O and related modules to include the
following:
Digital modules
Relay output modules
Analog modules
Specialty modules
Power supplies, wiring base assemblies, and miscellaneous module
Digital Modules
This table lists 1734 digital modules.
Digital Module Description Cat. No.
2, 4, and 8 sink input modules 1734-IB2, 1734-IB4, 1734-IB8, 1734-IB4D
2, 4, and 8 source input modules 1734-IV2, 1734-IV4, 1734-IV8
2, 4, and 8 sink output modules 1734-OV2E, 1734-OV4E, 1734-OV8E
2, 4, and 8 protected
source output modules
1734-OB2, 1734-OB4, 1734-OB8,
1734-OB2E, 1734-OB4E, 1734-OB8E
2 protected source output modules 1734-OB2EP
2 and 4 relay output modules 1734-OW2, 1734-OW4
2 relay output modules 1734-OX2
2 120/220V ac output modules 1734-OA2, 1734-OA4
2 120V ac input modules 1734-IA2, 1734-IA4
2 240V ac input modules 1734-IM2, 1734-IM4
