POINT I/O Module Data 119
The 1734D-IB8XOW8 module produces one byte of input data (scanner Rx)
status. It consumes one byte of output data (scanner Tx).
The 1734D-IA8XOA8 module produces one byte of input data (scanner Rx)
status. It consumes one byte of output data (scanner Tx).
76543210
Consumes
(scanner Tx)
Ch7 Ch6 Ch5 Ch4 Ch3 Ch2 Ch1 Ch0 Output Data (or
state)
Where: 0 = off, 1 = on
Default Data Map for the 1734D-IB8XOW8 dc Input/Relay Output Module
Message Size: 1 Byte
76543210
Produces
(scanner Rx)
Ch7 Ch6 Ch5 Ch4 Ch3 Ch2 Ch1 Ch0 Input Data
Where: 0 = off, 1 = on
Message Size: 1 Byte
76543210
Consumes
(scanner Tx)
Ch7 Ch6 Ch5 Ch4 Ch3 Ch2 Ch1 Ch0 Output Data
Where: 0 = off, 1 = on
Default Data Map for the 1734D-IA8XOA8 ac Input/Output Module
Message Size: 1 Byte
76543210
Produces
(scanner Rx)
Ch7 Ch6 Ch5 Ch4 Ch3 Ch2 Ch1 Ch0 Input Data
Where: 0 = off, 1 = on
Message Size: 1 Byte
76543210
Consumes
(scanner Tx)
Ch7 Ch6 Ch5 Ch4 Ch3 Ch2 Ch1 Ch0 Output Data
Where: 0 = off, 1 = on
Default Data Map for the 1734D-IB8XOB8E dc Input/Output Module
