Rockwell Automation POINTBlock Series User Manual

Publication 1734-UM001D-EN-P - April 2008
32 Install POINT I/O Modules
ATTENTION
When connecting more than one wire in a termination point,
make sure that both wires are the same gauge and type.
System
Power
DeviceNet
Power
Network
Status
Module
Status
1734
OB8E
3
2
0
1
7
6
4
5
Network
Status
Module
Status
1734
IB8
3
2
0
1
7
6
4
5
24V dc
24V dc Return
Prox
Prox
Prox
Prox
Prox
Prox
Prox
Prox
Terminal Block with Bus connector strip
DeviceNet
Example of Wiring - 1734-IB8 Module Using 2-Wire Proximity Switches
Terminal Block with Bus Connector Strip
