Rockwell Automation POINTBlock Series User Manual

Publication 1734-UM001D-EN-P - April 2008
96 Install POINTBlock I/O Modules
DeviceNet Connector Wiring
Channel Input Terminal Common Voltage
Remote Termination Block 0
Field Power
Block
Vin (supply) 6 and 7
Common) 4 and 5
Remote Termination Block 1
00 4 6
11 5 7
22 4 6
33 5 7
Remote Termination Block 2
40 4 6
51 5 7
62 4 6
73 5 7
Remote Termination Block 3
80 4 6
91 5 7
10 2 4 6
11 3 5 7
Remote Termination Block 4
12 0 4 6
13 1 5 7
14 2 4 6
15 3 5 7
Connect common on 3-wire proximity switches.
12/24V dc is supplied through the internal power bus.
ATTENTION
When connecting more then one wire in a termination point,
make sure that both wires are the same gauge and type.
DeviceNet
Connection
Red
White
Bare
Blue
Black
-V
42132
+V
CAN - High
Shield
CAN - Low
