Protocol Analysis
R&S
®
RTM20xx
160User Manual 1317.4726.02 ─ 01
11.2.3.2 SPI/SSPI Trigger Settings
The complete SPI/SSPI trigger is configured in the "Source" and "Setup" menus.
Triggers are only available if "Decode" is enabled.
● SPI/SSPI Trigger Source......................................................................................160
● SPI/SSPI Trigger Setup........................................................................................160
SPI/SSPI Trigger Source
Access: TRIGGER SETUP > "Trigger Type" = "Protocol (SPI or SSPI)" > "Source"
B1, B2, B3, B4
Select one of the configured and decoded buses as trigger source.
SPI/SSPI Trigger Setup
Access: TRIGGER SETUP > "Trigger Type" = "Protocol (SPI or SSPI)" > "Setup"
SPI/SSPI Bus (Option R&S RTM-K1)
