Remote Control
R&S
®
RTM20xx
368User Manual 1317.4726.02 ─ 01
Firmware/Software: FW 03.700
SEARch:TRIGger:RUNT:WIDTh <Width>
Sets the reference runt pulse width, the nominal value for comparisons.
Parameters:
<Width> Range: Depends on various settings, mainly time base and
sample rate
*RST: 200e-6
Default unit: s
Firmware/Software: FW 03.700
SEARch:TRIGger:RUNT:DELTa <DeltaWidth>
Sets a range Δt to the reference pulse width set with SEARch:TRIGger:RUNT:WIDTh
if SEARch:TRIGger:RUNT:RANGe on page 367 is set to WITHin or OUTSide.
Parameters:
<DeltaWidth> Range: Depends on various settings, mainly time base and
sample rate
*RST: 50e-6
Default unit: s
Firmware/Software: FW 03.700
15.2.12.7 Data2Clock Search Configuration
SEARch:TRIGger:DATatoclock:CSOurce.........................................................................368
SEARch:TRIGger:DATatoclock:CLEVel............................................................................369
SEARch:TRIGger:DATatoclock:DLEVel............................................................................369
SEARch:TRIGger:DATatoclock:CLEVel:DELTa.................................................................369
SEARch:TRIGger:DATatoclock:DLEVel:DELTa.................................................................369
SEARch:TRIGger:DATatoclock:CEDGe...........................................................................369
SEARch:TRIGger:DATatoclock:HTIMe.............................................................................369
SEARch:TRIGger:DATatoclock:STIMe.............................................................................370
SEARch:TRIGger:DATatoclock:CSOurce <ClockSource>
Selects the input channel of the clock signal.
Parameters:
<ClockSource> CH1 | CH2 | CH3 | CH4 | MA1 | MA2 | MA3 | MA4 | MA5 | RE1 |
RE2 | RE3 | RE4
*RST: CH1
Firmware/Software: FW 03.800
Command Reference
