DBP Digital Beltpack Icons | en 91
Bosch Security Systems, LLC
Technical Manual
2021-06 | 01 | F.01U.380.825
Audio Enter the Audio menu
Headset Enter the Headset menu
Sidetone Adjust the Sidetone.
The type of sidetone adjustment (XLR, Bluetooth, or
3.5mm) is dependent upon the active mic selection made
in the Mic Select menu
Echo Canceller Enable/Disable the Echo Canceller
Microphone Enter the Microphone menu
Mic Select Select the Active Mic
Mic Gain Adjust Mic Gain
The type of mic gain adjustment (XLR, Bluetooth, or
3.5mm) is dependent upon the active mic selection made
in the Mic Select menu
Hot Mic Enable or Disable Hot Mic
Noise Gate Adjust the Noise Gate level
The type of noise gate adjustment (XLR, Bluetooth, or
3.5mm) is dependent upon the active mic selection made
in the Mic Select menu.
XLR Mic Type Select the XLR Mic Type
Allow Mic Kill Enable or Disable Mic Kill
Send Mic Kill Send Mic Kill Signal
3.5mm Aux Enter the 3.5mm Aux Menu
Aux Mode Configure the Aux Mode
Input Gain Adjust Aux Input Gain
Output Gain Adjust Aux Output Gain
BT Aux Levels Enter BT Aux Levels menu
Input Gain Adjust Bluetooth Input Gain
Output Gain Adjust Bluetooth Output Gain
OMNEO Ch2 Levels Enter OMNEO Ch2 Levels menu
Input Gain Adjust OMNEO Ch 2 Input Gain
Output Gain Adjust OMNEO Ch 2 Output Gain
Mixer Enter the Mixer menu
