94 en | Technical data DBP Digital Beltpack
2021-06 | 01 | F.01U.380.825
Technical Manual
Bosch Security Systems, LLC
Frequency Response (600 Ohm load) 25 Hz to 20 kHz
OMNEO Ports (PoE In and PoE Out)
Maximum Capacity: 2 Full-duplex ports
Copper Connector Type: RJ-45
Format: IEEE 802.3 compliant
Copper Ethernet Speed: 100/1000 Mbps
Bluetooth
Bluetooth Version: 4.0
Supported dongles: IO Gear GBU522
LM Technologies LM506
Range: 15 ft. (5 m)
Audio Codec: SBC
TFT Display
Active Area: 27.72 mm (wide) x 27.72 mm (high)
Dot Resolution: 240 x 240 pixels
Color Resolution: 16-bit (64 K) RGB color
View Angle: 80° (typical, all directions)
Protective Lens: Anti-glare / Anti-reflective
Approvals:
CE compliant
UL certified
IP-53 rated (ingress protection)
Connector pin-outs
PoE Connector
RJ45 Pin Data Power
Pin 1 Rx Pair 1 DC+
Pin 2 Rx Pair 1 DC+
Pin 3 Tx Pair 2 DC-
Pin 4 Not used for 10/100 Pair 3 DC+
Pin 5 Not used for 10/100 Pair 3 DC+
Pin 6 Tx Pair 2 DC+
Pin 7 Not used for 10/100 Pair 4 DC-
Pin 8 Not used for 10/100 Pair 4 DC-
