DBP Digital Beltpack Technical data | en 95
Bosch Security Systems, LLC
Technical Manual
2021-06 | 01 | F.01U.380.825
Headset Connector
5-Pin Dynamic 5-Pin Electret 4-Pin Dynamic 4-Pin Electret
Pin 1 Mic - Ground Mic - Ground
Pin 2 Mic + Mic Mic + Mic
Pin 3 Speaker - Speaker - Speaker - Speaker -
Pin 4 Left Speaker + Left Speaker + Speaker + Speaker +
Pin 5 Right Speaker + Right Speaker + N/A N/A
Aux /3.5mm Connector
Headset Mode Aux Input Aux Output
Tip Left Speaker Left Input Left Output
Ring 1 Right Speaker Right Input Right Output
Ring 2 Ground
Sleeve Mic Ground Ground
USB Connector
Pin Data
Pin 1 +5V
Pin 2 Data -
Pin 3 Data +
Pin 4 Ground
