5 – 4 HS40 Service Manual
The major structure of this product includes the following:
Ultrasound System Part
• PSA (Probe Select Assembly) 4 Ports
• BF (Beamformer Board) 1ea 128ch
• BE (Back End Board)
• USB ECG Module
• USB Foot Switch
• Gel Warmer
• FAN Module
User Interface Part
• 21.5” LCD main monitor
• 10.1” LCD touch panel
• Key Matrix Board
• Up/Down, Swivel, CP
• 1.2” Track Ball
PC Part
• PC Module: Advantech , Com Express Module
CPU: AMD 2.7GHz, R-Series
• RAM: DDR3 SDRAM 8GB
• Storage: HDD 500GB SATA-2 2.5” , 7200RPM
• VGA: Internal Graphic Chip (Radeon HD9000)
Power Module ADM
