8 – 12 HS40 Service Manual

8.2.8. Monitor ARM Disassembly

Remove 1 screw and detach the HDMI Cable. Then, disconnect 1 Power Connector. Lastly,

remove 4 heavy duty screws fixing the ARM in place and detach the Monitor Arm by lifting it up.
