Samsung HS40 - Power Block Diagram; Specification

5 – 30 HS40 Service Manual
5.7.2. Power Block Diagram
[Figure 5.23 HS40 ADM Block Diagram]
5.7.3. Specification
ITEM SPECIFICATION
Standard Input voltage 100VAC – 240VAC
Absolute Maximum Input 77VAC – 286VAC
OUTLET
100VAC – 240VAC / MAX 150VA for internal hospital
grade peripheral
Power consumption MAX 800VA
Protection mode OCP, O V P, UV P, O TP
