1 – 2 HS40 Service Manual
1.1. Product Specifications
Physical
Dimensions
Height: 1,620 mm (with Monitor)
Width: 520 mm
Depth: 730 mm (with Keyboard)
Weight: 54 kg (without accessories)
Weight: Approx. 57 kg (with Safe Working Load)
Imaging Modes
2D Mode
M Mode
Color M Mode
Anatomical Mode
Color Doppler Mode
Pulsed Wave (PW) Spectral Doppler Mode
Continuous Wave (CW) Doppler Mode
Tissue Doppler Imaging (TDI) Mode
Tissue Doppler Wave (TDW) Mode
Power Doppler (PD) Mode
ElastoScan Mode
3D/4D/XI STIC imaging Mode
Dual Mode
Quad Mode
Combined Mode
Simultaneous Mode
Zoom Mode
Gray Scale 256 (8 bits)
Focusing
Transmit focusing, maximum of eight points (four points simultaneously
selectable)
Digital dynamic receive focusing (continuous)
Probes
(Type BF/IPX7)
Linear Array
LA3-16AD
Curved Array
CA2-8AD, CF4-9
Phased Array
PN2-4
Endo Cavity
EVN4-9
3D
VN4-8, V5-9
