Samsung HS40 - Rear IO Board

Chapter 5. Product Structure 5 – 21
5.5.2. Rear IO Board
It serves as an In/Out Interface with external devices and also as a data interface with the
control panel. This board handles the image output for both the screen display and the touch
screen. It provides a VHS, S-VHS, and DVI Port to support various means of externally storing
images.
REAR
RCA-LR
RCA-LW
S-VIDEO
AP&I
US B X2
HDMI
LAN
I
N
O
U
T
SOUND
HS50 기준
D-SUB
US B X2
[Figure 5.14 Rear IO Board & Layout]
