Samsung HS40 - Cable Description

5 – 32 HS40 Service Manual
5.8.2. Cable Description
5.8.2.1. Cable
NO CIS CODE SPECIFICATION Signal
Lock Type
Description
A B
A-1 MI3 9 -02065A
CBF CABLE-
HS50_CP_TRACKBALL
USB2.0 Lock Lock TR AC KBALL
A-2 MI3 9 -02030A
CBF CABLE-
HS50_BW_PRINTER_USB
USB2.0 Lock unLock USER PRINTER
A-3 MI3 9 -02056A
CBF CABLE-
HS50_PRINTER_POWER
POWER Lock unLock AUX PRINTER
A-4 MI3 9 -02173A CBF-USB-BP-CP USB2.0 Lock Lock CP USB
A-5 MI3 9 -02025A
CBF CABLE-
HS50_ECG_USB
USB2.0 Lock unLock ECG
A-6 MI3 9 -02006A
CBF CABLE-GEL
WARMER_LEFT
POWER
Bracket unLock GELWARMER(12V)-Ex
A-7 MI3 9 -02174A CBF-GEL WARMER-CP POWER Lock Bracket GELWARMER(12V)-In
A-8 MI3 9 -02184A CBF-TOTAL -BP-CP POWER Lock Lock
CP Power (5V, 12V,
SIGNAL)
A-9 MI3 9 -02172A CBF-S ATA-HDD-BP Signal Lock Lock HDD(5V, 12V, S ATA)
A-10 MI39-02171A CBF-GND NA NA GND CABLE
A-11 MI39-02176A CBF-FAN -BP-BOTTOM POWER Lock NA FAN(12V)
A-12 MI39-02177A CBF-FAN -BOTTOM-EXT POWER Lock Lock
FAN(12V) Extension –
Internal
A-13 MI39-02178A CBF-HDMI-TOUCH-BP HDMI Lock Lock TOUCH HDMI
A-14 MI39-02181A CBF-POWER-BP-AR M POWER Lock Lock Monitor Power ARM In 1
A-15 MI39-02182A CBF-POWER-ARM POWER Lock Lock Monitor Power ARM In 2
A-16 MI39-02179A CBF-HDMI-AR M-BP HDMI Lock Bracket Monitor HDMI In 1
A-17 MI39-02180A
CBF-HDMI-ARM-
MONITOR
HDMI
Bracket Bracket Monitor HDMI In 2
A-18 MI39-02183A CBF-SOUND-BP Signal Lock Lock SPEAKER
A-19 MI39-01647B CBL-EVE-USB-HUB-DCK USB2.0 Lock Lock AL PH AKEYBOAR D EXT
A-20 MI39-02203A
CBF-USB-
ALPH AKEYBOAR D
USB2.0 Lock unLock KEYBOARD In
A-21 MI39-02061A TOUCH USB CABLE USB2.0 Lock Lock TOUCH USB
A-22 MI39-02202A TOUCH POWER CABLE POWER Lock Lock TOUCH POWER
A-23 MI39-01378A AC Cord POWER AC CORD
[Figure 5.25 Cable]
