5 – 26 HS40 Service Manual
5.6.2. Main Monitor
A 21.5" Samsung Full-HD Wide LED Panel is used.
[Figure 5.19 Main Monitor]
5.6.2.1. Specification
ITEM SPECIFICATION UNIT
Display area 21.5” Samsung Display Inch
Number of Pixels 1920 x 1080 RGB stripe arrangement Pixels
Pixel Pitch 0.2475 (H) x 0.2475 (V) mm
Electrical Interface LCD Panel Input: HDMI
Display colors 16.7M colors (Hi-FRC)
Viewing angle 89°/89°/89°/89° (CR≥10)
Display mode Normally Black
To Next Page
