1 – 20 HS40 Service Manual
Connecting or removing the Foot Switch while the product is turned on may
cause the system to malfunction.
■ Mi sc.
Flash Memory Media
NOTE
The system cannot recognize USB 1.1 flash memory. Remove the flash
memory from the console and equip again with an appropriate device.
Regarding file formats that are not ordinarily saved: Please check first to see
if it is possible to save the file format on a desktop PC before trying to save
the file on flash memory.
Do not use flash memory media which contain anti-virus programs or are
defective. Otherwise, the product may fail to work properly.
1.2.5. Probes
Probes are devices that generate ultrasound waves and process reflected wave data for the
purpose of image formation.
NOTE
For information on probes, refe
r to ‘Chapter 9. Probes’ and the Reference
1.2.5.1. Connecting Probes
Be sure to connect or disconnect probes when the power is off to ensure the safety of the syste
m and the probes.
1. Connect probes to the probe connectors on the front panel of the system. Up to four (options
inclusive) (five including CW) probes may be connected.
2. Lift up the probe’s lockdown switch and disconnect the probe.
3. Connect the probe to the probe port.
4. Push down the probe’s lockdown switch to lock it in place.
NOTE
does not connect properly, try reconnecting it after removing any
