Chapter 1. Introduction 1 – 3
DP2B
Probe
Connections
3 Probe Connectors, 4 Probe Connectors for option
CW Probe Connector
Monitor
Main Monitor
Number of Pixel: 1920 x 1080
21.5 inch LCD Monitor (LED Backlight unit, hereafter referred to as “LCD
monitor”)
Touch Screen Monitor
Number of Pixel: 1280 x 800
10.1 inch LCD Monitor (LED Backlight unit, hereafter referred to as “LCD
monitor”)
ECG USB Type (Type CF)
Rear Panel
Input/Output
Connections
Audio Output Port (Right/Left)
VGA monitor
LAN
USB Port
CW
HDMI output
HDMI Input (HDMI Input is currently not supported.)
Image Storage
Maximum 45,000 frames for Cine memory
Maximum 14,000 Lines for Loop memory
Image filing system
Application
Obstetrics, Gynecology, Urology, Abdomen, Cardiac, Vascular, Small
Parts, TCD, MSK, Pediatric
Electrical
Parameters
100 - 240VAC, 620VA, 50/60Hz
Measurement
Packages
Abdomen, Obstetrics, Gynecology, MSK, Pediatric, Small Parts, Urology,
Vascular, Cardiac
* Refer to the ‘Chapter 8. Measurements and Calculations’ for additional
information.
Signal
Processing
(Pre-processing)
Acoustic Power Control
Analog TGC Control
Dynamic Aperture Control
Dynamic Apodization Control
