1 – 4 HS40 Service Manual
Signal
Processing
(Post-
processing)
Digital TGC Control
Slider TGC Control
Mode-Independent Gain Control
Black Hole/Noise Spike Filtering
1D Lateral/Axial Filtering
2D Edge/Blurring Filtering
Frame average
M/D Mode Sweep Speed Control
Zoom
Image View Area Control
Image Orientation (left/right and up/down)
Measurement
Trackball operation of multiple cursors
• 2D mode: Linear measurements and area measurements using
elliptical approximation or trace
• M mode: Continuous readout of distance, time, and slope rate
• Doppler mode: Velocity and trace
Auxiliary
DVD Multi-Dri ve
Digital B/W Video Printer
Digital Color Video Printer
USB Printer
DVD Recorder
Foot switch (IPX8)
USB Flash Memory Media
USB HDD
USB ECG
Monitor
User Interface English, German, French, Spanish, Italian, Russian, Chinese, Portuguese
Pressure Limits
Operating: 700 – 1060hPa
Storage: 700 – 1060hPa
Humidity Limits
Operating: 30 – 75%
Storage & Shipping: 20 – 90%
Temperature
Limits
Operating: 10 – 35°C
Storage & Shipping: -25 – 60°C
