9 – 8 HS40 Service Manual
Probe Application Biopsy TDW CW
Multi
Vision
Clear Vision S-Ha r. Har
OB O X X O O O O
GYN O X X O O O O
MSK O X X O O O O
Pediatric O X X O O O O
Vascular O X X O O O O
Urology O X X O O O O
V5-9
OB O X X O O O O
GYN O X X O O O O
Urology O X X O O O O
DP2B
Cardiac X X O X X X X
Vascular X X O X X X X
NOTE
The significance of each symbol is as follows:
– Q Scan: Quick Scan
– Har: Harmonic Imaging
– S-Har: S-Harmonic Imaging
– ECG: Electrocardiograph Imaging
– CM: Color M
– TDI: Tissue Doppler
– PD: Power Doppler
– S-Flow: Directional Power Doppler Imaging
– TDW: Tissue Doppler Wave
– CW: Continuous Wave
MultiVision is only available in 2D/C Mode.
To Next Page
