9 – 24 HS40 Service Manual
9.2.2.2. Biopsy Procedure
The system generates a needle guideline though the displayed real-time ultrasound images to
indicate the anticipated path of the needle. You can use this guideline to ensure that the needle
or instrument is following the correct path.
1. Ready the patient according to the procedure appropriate for the examination objectives.
2. Install the sheath and the biopsy kit.
3. Set the system controls for the biopsy procedure. If necessary, apply acoustic gel to the
patient.
4. Scan the patient. Adjust the patient so that the location for examination fits into the needle
guideline on the screen.
5. Insert the needle into the needle guide for use. Perform the puncture by sliding the needle
through the groove in the guide until the needle intercepts the target.
To keep the needle securely in the needle guide, press down on the top of the biopsy
adapter with your index finger.
6. When the examination location is reached, take the needle out of the needle guide.
7. Detach the needle guide, adapter and sheath from the probe.
8. Discard all disposable items following use.
