Machine overview
22
1. Introduction
K325x/ K330x series
If you want to see the imaging unit, you need to remove the waste toner
container.
12
Rear view
1 Waste toner container
2 Toner cartridge
3Imaging unit
1
2
3
1 Output support tray
2 Control board cover
3USB memory port
4USB port
5 Network port
6
Cover for optional FDI kit
a
a. Open this cover to install the optional device.
7
Cover for optional Fax1 port
a
2
1
6
7
5
4
3
