Chapter 1 Before Installation
RF4402d Series Installation Manual v1.0 5
Copyright © 2018, All Rights Reserved.
Specifications
The table below lists the main specifications of the RRH.
Table 1. RRH Specifications
Item RF4402d-D1A
Technology 3GPP Rel. 13
Duplex type FDD
Operating Frequency Band66 (2,100 MHz)
DL: 2,110 to 2,180 MHz
UL: 1,710 to 1,780 MHz
Band2 (1,900 MHz)
DL: 1,930 to 1,990 MHz
UL: 1,850 to 1,910 MHz
Channel Bandwidth 5 MHz, 10 MHz, 15 MHz, 20 MHz
2Tx2Rx/2Tx4Rx/4Tx4Rx per RRH
Input Voltage -48 V DC (-38~-57 V DC)
Input Current 17 A @ - 48 V DC
Dimension (W × D × H) 11.81 in.(300 mm) × 9.25 in.(235 mm) × 14.96 in.(380 mm)
Weight (kg) Approx. 28.5
Operating Temperature
(Ambient)
-40~55°C (without solar load)
Operating Humidity 5~100 % RH, condensing, not to exceed 30 g/m
3
absolute
humidity
Altitude (m) -60~1,800 (Telcordia GR-63-CORE)
Earthquake Telcordia Earthquake Risk Zone4 (Telcordia GR-63-CORE)
Vibration Office Vibration (Section 4.4.4)
Transportation Vibration (Section 4.4.5)
Noise Fanless (natural convection cooling)
EMC FCC Title 47 CFR Part 15
Safety UL 60950-1 2nd Ed.
RF FCC Title 47 CFR Part 27
