Chapter 3 Connecting Cables
RF4402d Series Installation Manual v1.0 76
Copyright © 2018, All Rights Reserved.
Install a circuit breaker to a AC distributor for the stable power. The capacity of
circuit breaker is 20 A. (Use UL Listed circuit breakers.)
Connecting Power Cable
Connecting RRH Power Cable
To connect RRH DC Power cable
1 Make sure you have the following items:
Table 27. Parts and Tools for connecting RRH DC Power Cable
Category Description
Installation
Section
AC/DC Convertor(or Site Rectifier) ~ RRH Power Port
Cable 8 AWG × 2C
Bend Radius Operation: 8 × OD Installation: 12 × OD
Connector AC/DC Convertor JONHON, Push Pull Type, CT48J-1502TSCBM-07
* Check specifications of rectifier output terminal per site and prepare fasteners when
connect RRH power cable to the site rectifier
RRH JONHON, Push Pull Type, CT48J-1502TSCBM-07
Working Tools
 Cable Cutter
 Wire Stripper
 Compressor
 Heating Gun
 Nipper
Table 28. RRH DC Power Cable Connector Pin Map
Power Connector
Pin No.
Description Color
Pin 1 -48 V DC White
Pin 2 RTN Black
* The color of the core wire can be changed according to the specification of the cable used.
