Chapter 2 Installing System
RF4402d Series Installation Manual v1.0 30
Copyright © 2018, All Rights Reserved.
2
While Operator A hauls the rope to carry up the RRH/mounting bracket
assembly, Operator B pulls the rope outward so that RRH/mounting bracket
assembly would not hit the tower platform.
Figure 24. Lifting RRH & Mounting Bracket Assembly
Pulley
RRH/Mounting Bracket Assembly
Tower Platform
Rope
Operator A Operator B
