Chapter 3 Connecting Cables
RF4402d Series Installation Manual v1.0 67
Copyright © 2018, All Rights Reserved.
Table 23. RRH Connection Cable
From To Cable
MGB RRH 1 Ground Cable
: 6 AWG × 1C
RRH AC/DC Convertor
(or Site Rectifier)
2 DC Power Cable
: 8 AWG × 2C
CDU 3 CPRI Cable
: Single Mode (Outdoor Type)
External Device 4 UDA Cable Assembly
RF Antenna 5 RET Cable Assembly
6 RF Cable
: 1/2 in. Feeder Line
