Chapter 2 Installing System
RF4402d Series Installation Manual v1.0 29
Copyright © 2018, All Rights Reserved.
Lifting RRH & Mounting Bracket Assembly
To lift RRH/Mounting Bracket Assembly
1
Tie the rope in two carrying points of RRH and Mounting bracket assembly.
Figure 23. Lifting RRH & Mounting Bracket Assembly
[Lifting Mounting Bracket Assembly]
[Lifting RRH]
Carrying
Point_1
Carrying
Point 2
Carrying
Point_1
Carrying
Point 2
To Next Page
