Chapter 2 Installing System
RF4402d Series Installation Manual v1.0 49
Copyright © 2018, All Rights Reserved.
Lifting RRH & Mounting Bracket Assembly
1 sector pole 설치의 ‘lifting RRH & mounting bracket assembly’ 공정을
참조하여 RRH 와 mounting bracket assembly 를 인양한다.
Figure 44. Lifting RRH & Mounting Bracket Assembly
Pulley
RRH/Mounting Bracket Assembly
Tower Platform
Rope
Operator A
Operator B
To Next Page
