When fixing a pole mounting bracket, the length of a stud bolt is 200 mm for the
pole diameter 50~80 A and 230 mm for the pole diameter 80~100A.
Pole Size (Diameter) Length of Stud Bolt
50 A (60.5 mm) 200 mm
65 A (76.3 mm)
80 A (89.2 mm) 200 mm or 230 mm
90 A (101.6 mm) 230 mm
100 A (114.3 mm)
메모 포함[H3]: The different length of stud bolt is just for
back to back pole mounting. If there is no back to back case,
230mm can be used for the pole diameter 50~100A.
