Interfaces
Cubis MSU User Manual 133
Explanations for the Setting Parameters
Selected Protocol/Handshake
The SBI (Sartorius Balance Interface) has transmit and receive buffers. Data trans-
mission can be operated with a hardware or software handshake.
.
Hardware Handshake (CTS/DTR): With a hardware handshake (4-wire interface) protocol, the handshake is controlled
via the CTS and DTR lines.
Software Handshake (XON, XOFF): The software handshake is controlled via the XON and XOFF control commands.
When the device is switched on, XON must be transmitted to enable any connected
device to communicate.
Data transmission:
Balance ––– byte –––> PC
(transmitting device) ––– byte –––> (receiving device)
––– byte –––>
––– byte –––>
<––XOFF –––
––– byte –––>
––– byte –––>
…
(Pause)
…
<––XON –––
––– byte –––>
––– byte –––>
––– byte –––>
––– byte –––>
Transmitting Device: Once XOFF has been received, it prevents further transmission of characters. Once
XON has been received it re-enables the transmitting device to send data.
Receiving Device: To prevent too many control commands from being received at one time, XON is
not transmitted until the buffer is almost empty.

Sartorius Cubis Series Specifications

General

Display	Color touch screen
Readability	0.01 mg to 1 g
Interfaces	USB, Ethernet, RS-232
Calibration	Internal and external
Housing	Die-cast aluminum
Response Time	Varies by model
Pan Size	Varies by model
Operating Temperature	10°C to 30°C
Compliance	GLP
Power Supply	100 – 240 V, 50/60 Hz
Capacity	Varies by model (up to 64 kg)
Repeatability	Varies by model
Linearity	Varies by model
