t Place the pan support diagonally and press down lightly.
1. Pan support
t Carefully turn the pan support clockwise until the two buttons
engage. The pan support is now attached.
t 2. Insert the shield plate/draft shield.
t 3. Place the weighing pan on the pan support.
y This completes the balance assembly.
Models MSx225..., MSx125... (Semi-microbalances):
Connecting the Weigh Cell to the Electronics Module
t Connect the weigh cell and electronics module using the connection cable.
14 Cubis MSU User Manual
Getting Started
